Anthem MRX 1140 8k AV Receiver Flagship

The Anthem MRX 1140 8K is not just an A/V receiver; it is the culmination of our relentless pursuit of sonic perfection and technical innovation. As a cornerstone of the award-winning MRX Series, the 1140 8K delivers an uncompromising blend of performance and value, a testament to our independent engineering philosophy. With 15.2 pre-amplifier channels and 11 amplifier channels providing a conservative 140 watts each into 8 ohms, this is the ultimate power center for discerning audiophiles and home theater enthusiasts. It is an instrument of precision, designed to deliver unadulterated audio and video performance.Anthem’s MRX A/V receivers are meticulously engineered to maximize audio performance, reaching levels previously unobtainable at their price points. The MRX 1140 8K builds upon this foundation by incorporating the newest version of ARC Genesis with a redesigned, more accurate calibration microphone, Anthem’s intuitive Web User Interface, and robust integrated streaming support. It features object-oriented audio codecs with support for up to 15.2 channels, ensuring an immersive sound experience. The new electronics platform includes HDMI 2.1 with HDCP 2.3, offering 7 dedicated 8K HDMI inputs that support 8K/60Hz or 4K/120Hz pass-through, along with three dedicated outputs, including eARC.

Technical Specs:

• Number of Power Amps

  11

• Maximum Continuous Output (1% THD) (20Hz – 20kHz, Two Channels Driven @ 8Ω) Channels: 1~5

  140 W

• Maximum Continuous Output (1% THD) (20Hz – 20kHz, Two Channels Driven @ 6Ω) Channels: 1~5

  170 W

• Maximum Continuous Output (1% THD) (20Hz – 20kHz, Two Channels Driven @ 8Ω) Channels: Remaining

  60 W

• Maximum Continuous Output (1% THD) (20Hz – 20kHz, Two Channels Driven @ 6Ω) Channels: Remaining

  75 W

• Channels

  15.2

• Max Speaker Configuration

  9.2.6

• Room Correction

  Yes

• High-Resolution Audio

  Yes – FLAC, ALAC, WAV, DSD

• DTS HD Master, DTS:X

  Yes, Yes

• DTS Neural:X

  Yes

• DTS Virtual:X

  Yes

• IMAX Enhanced

  Yes

• Dolby TrueHD, Dolby Atmos, Dolby Atmos Music

  Yes, Yes, Yes

• Dolby Surround

  Yes

• Multichannel Stereo

  Yes

• AnthemLogic-Music, AnthemLogic-Cinema

  Yes, Yes

• Max. Number of Processing (Pre-Amp) Channels

  15.2

• HDMI Inputs / Outputs

  7 In / 2 Out

• Zone 2 HDMI Ouput

  1 Out

• HDMI Version

  HDMI 2.1

• HDR Support

  HDR10, HDR10+, Dolby Vision, HLG, Dynamic HDR

• HDCP Version

  HDCP 2.3

• eARC

  Yes

• Gaming Features

  VRR, ALLM, QFT

• Analog Inputs

  5 In

• Line Output

  1 Out

• Phono Input (MM)

  No

• Digital Inputs (Coax)

  2 In

• Digital Inputs (Optical)

  3 In / 1 Out

• Pre-amplifier Outputs

  Yes – 15.4

• Subwoofer Outputs

  2 (Independent)

• USB Port

  1 – 5V/500mA (Service) (USB-A)

• Speaker Terminals

  FR, FL, C, SR, SL, BR, BL, WR, WL, H1R, H1L, H2R, H2L

• Front Display

  6″ TFT

• Construction

  Aluminum Chassis with Machine Aluminum Faceplate

• Weight

  33.6 lb (15.2 kg)

• Dimensions (W)

  17″ (43.18 cm)

• Dimensions (D)

  14-1/2″ (36.4 cm)

• Dimensions (H)

  6″ (15.24 cm)

• Height with Rackmount Kit

  4U

• Speaker Impedance

  4Ω
